SJLITE SAC T8 SURFACE DIFFUSED FITTING 240V IP20 CLASS 1 [2FEET/4FEET] [SAC 120/ SAC 220/ SAC 320/ SAC 420/ SAC 140/ SAC 240/ SAC 340/ SAC 440]

SJLITE SAC T8 SURFACE DIFFUSED FITTING 240V IP20 CLASS 1 [2FEET/4FEET] [SAC 120/ SAC 220/ SAC 320/ SAC 420/ SAC 140/ SAC 240/ SAC 340/ SAC 440]

Category: FITTINGS

Specifications
Wattage (W)
1 x 18W/ 2 x 18W/ 3 x 18W/ 4 x 18W 1 x 36W/ 2 x 36W/ 3 x 36W/ 4 x 36W
Voltage (V)
240V
IP Rating
IP20
Type
T8 SURFACE DIFFUSED FITTING
Features
Suitable for ceiling or pendant mounting with suspension system. Mirror reflector held securely by treaded nut, offering large screw area using hand for fast installation. Allow a wide and efficient distribution of light. End to end continuously mounting from performed punch out type without additional drilling required
Application
Ideal for use where lighting needs to be concentrated on certain area
WATTAGE
SAC 120 : 1 x 18W , SAC 220 : 2 x 18W, SAC 320 : 3 x 18W , SAC 420 : 4 x 18W , SAC 140 : 1 x 36W , SAC 240 : 2 x 36W , SAC 340 : 3 x 36W , SAC 440 : 4 x 36W
Details

SJLITE SAC T8 SURFACE DIFFUSED FITTING 240V IP20 CLASS 1 [2FEET/4FEET] [SAC 120/ SAC 220/ SAC 320/ SAC 420/ SAC 140/ SAC 240/ SAC 340/ SAC 440]





Product Description:

Upgrade your lighting system with the SJLITE SAC T8 Surface Diffused Fitting, designed for efficient and uniform illumination. This high-performance fitting is compatible with T8 fluorescent tubes and operates at 240V, rated IP20 for indoor use and Class 1 safety. Ideal for commercial, industrial, and residential applications, it combines functionality with sleek surface-mounted design.

Available in multiple configurations, the SJLITE SAC T8 fitting comes in both 2 feet and 4 feet lengths and supports a range of wattages to meet different brightness requirements:

  Wattage Options:

  • 1 x 18W / 2 x 18W / 3 x 18W / 4 x 18W (for 2FT fittings)

  • 1 x 36W / 2 x 36W / 3 x 36W / 4 x 36W (for 4FT fittings)

  Model Variants:

  • SAC 120 / SAC 220 / SAC 320 / SAC 420

  • SAC 140 / SAC 240 / SAC 340 / SAC 440

Each unit features a diffused cover for glare-free lighting and a durable surface-mounted body, making it easy to install on ceilings or walls. Whether you're retrofitting or building new, this fitting is an energy-efficient and reliable choice for modern lighting solutions.
